IR2104 / IR2104S — Half-Bridge Gate Driver IC

The IR2104 (DIP-8) and IR2104S (SOP-8) are popular half-bridge gate driver ICs from Infineon (formerly International Rectifier), widely used to drive N-channel MOSFETs and IGBTs in half-bridge and full-bridge power converter topologies. With a built-in bootstrap circuit, shoot-through protection, and 600V high-side capability, the IR2104 is the go-to gate driver for motor drives, inverters, and DC-DC converters in Pakistan.

Technical Specifications

Parameter	Value
Part Number	IR2104 (DIP-8) / IR2104S (SOP-8)
Type	Half-Bridge Gate Driver
High-Side Voltage (V₂offset)	Up to 600V
Gate Drive Supply (V₂CC)	10V – 20V
Output Current (Source/Sink)	130mA / 270mA
Propagation Delay	680ns (HO), 150ns (LO)
Input Logic	IN + SD (shutdown)
Shoot-Through Protection	Yes (built-in dead time)
Bootstrap Diode	External required
Packages	DIP-8 (IR2104), SOP-8 (IR2104S)

Key Features

600V high-side floating channel — drives high-side N-channel MOSFETs/IGBTs
Built-in shoot-through protection with matched propagation delays
SD (shutdown) input for hardware fault protection
Bootstrap operation — no isolated power supply needed for high-side drive
Available in DIP-8 (through-hole) and SOP-8 (SMD) packages
Compatible with 3.3V and 5V logic inputs

Applications

Half-bridge and full-bridge motor drives
DC-DC converters and synchronous rectifiers
BLDC motor controllers
Inverters and UPS systems
Class-D audio amplifiers

Buy IR2104 / IR2104S Half-Bridge Gate Driver IC online in Pakistan at the best price from Embeded Studio. Fast delivery across Lahore, Karachi, Islamabad, and all major cities.
