2-pin PCB connector right angle — 2.54mm pitch, through-hole, screw terminal

The 2-pin right-angle PCB connector is a compact, reliable screw-terminal block designed for through-hole PCB mounting. The 90° right-angle orientation routes wires parallel to the PCB surface, making it ideal for panel-mount enclosures, edge-mounted boards, and any application where vertical wire entry is not practical. The screw-clamp termination provides a tool-free, re-connectable, and vibration-resistant connection for power and signal wiring.

Key Specifications:

• Number of poles: 2
• Pitch: 2.54mm (0.1")
• Orientation: Right angle (90°) — wire entry parallel to PCB
• Termination: Screw clamp (tool-free wire insertion)
• Mounting: Through-hole PCB
• Wire gauge: 26–16 AWG (typical)
• Rated voltage: 300V (typical)
• Rated current: 8A (typical)
• Contact material: Copper alloy, tin plated
• Housing material: PA66 (nylon), UL94 V-0 flame retardant

Key Features:

• Right-angle wire entry — cable exits horizontally, ideal for rear-panel and edge-mount PCB designs
• Screw terminal — secure, re-connectable wiring without soldering to the wire
• 2.54mm standard pitch — compatible with common PCB footprints and breadboard spacing
• Compact 2-pole format — minimal board space for power or signal connections
• Flame-retardant housing for safety in enclosed electronics

Applications:

• Power input connections on PCBs (5V, 12V, 24V rails)
• Sensor and signal wiring in embedded systems
• LED driver and lighting PCB connections
• Motor driver power and control wiring
• Industrial control panel PCB wiring
• DIY electronics and prototyping projects
