ADC0809 8-Bit 8-Channel Analog to Digital Converter IC
VendorMy Store
SKU:ADC0809-IC

ADC0809 8-Bit 8-Channel Analog to Digital Converter IC

Rs.550.00
Sale price: Rs.550.00 Regular price: Sale: -0%
Shipping calculated at checkout.
Out of stock
Quantity

ADC0809 8-Bit 8-Channel Analog to Digital Converter IC

The ADC0809 is an 8-bit successive approximation ADC with an 8-channel analog multiplexer, widely used in 8051 microcontroller interfacing labs. It features a parallel output interface and on-chip address latch for channel selection.

Key Features

  • 8-bit resolution ADC
  • 8-channel analog multiplexer
  • Parallel output interface
  • On-chip address latch and decoder
  • Single supply: 5V
  • Conversion time: 100µs @ 640kHz clock
  • 28-pin DIP package

Applications

  • 8051 microcontroller ADC interfacing
  • Multi-channel data acquisition
  • Industrial process monitoring
  • Sensor array digitization
