DB50 female connector — 50-pin D-sub, crimp type, high-density

The DB50 female connector is a 50-pin high-density D-sub connector conforming to commercial industry standards. The crimp-style termination eliminates the need for soldering, making it ideal for field assembly and DIY wiring projects. Compatible with any standard female D-sub crimp contact, including the CPF family. Pairs directly with the DB50 male connector and is suitable for industrial control panels, data acquisition systems, CNC machines, and test equipment wiring.

Key Specifications:

• Type: DB50 female (socket/receptacle)
• Number of pins: 50
• Connector series: High-density D-sub (DB series)
• Termination: Crimp style
• Shell size: DB50 (size 1)
• Contact compatibility: Standard female D-sub crimp contacts (CPF family)
• Mounting: Cable mount
• Industry standard: Commercial D-sub specification

Key Features:

• Crimp termination — no soldering required, faster and cleaner assembly
• High-density 50-pin configuration in compact D-sub shell
• Compatible with standard DB50 male connectors and backshell covers
• Insertion/extraction tool recommended: TDT or TDTPRO

Applications:

• Industrial control and automation wiring
• Data acquisition (DAQ) systems
• CNC machine I/O connections
• Test and measurement equipment
• SCSI and legacy parallel interface cables

Note: Use with a DB50 backshell cover (sold separately) for strain relief and connector protection in cable-mount applications.
