ESP32-P4-M3 module — dual-core RISC-V, 32MB Flash, 16MB PSRAM, ISP, H.264

The ESP32-P4-M3 is a high-performance system-in-package (SiP) module from Espressif Systems, built around the ESP32-P4 SoC — a powerful dual-core RISC-V processor designed for demanding HMI, machine vision, and edge AI applications. Unlike previous ESP32 variants, the ESP32-P4 does not include built-in Wi-Fi or Bluetooth; wireless connectivity is achieved via a companion chip (e.g. ESP32-C6 or ESP32-H2) connected over SPI/SDIO.

Key Specifications:

• SoC: Espressif ESP32-P4
• CPU: Dual-core RISC-V (HP core @ up to 400 MHz, LP core @ 40 MHz)
• Flash: 32MB (octal SPI)
• PSRAM: 16MB (octal SPI)
• Image Signal Processor (ISP): built-in hardware ISP pipeline
• Video encoder: H.264 hardware encoder
• Display interface: MIPI-DSI (up to 1080p)
• Camera interface: MIPI-CSI (up to 4-lane)
• USB: USB 2.0 OTG (High Speed)
• Peripherals: SPI, I2C, I2S, UART, SDIO, TWAI (CAN), MCPWM, ADC, DAC
• Security: RSA-3072, AES-128/256, SHA, HMAC, digital signature
• Operating voltage: 3.3V
• Operating temperature: −40°C to +85°C
• Wireless: None on-chip (requires companion module)

Memory:

• On-chip SRAM: 768KB HP SRAM + 32KB LP SRAM
• External Flash: 32MB (on module)
• External PSRAM: 16MB (on module)

Key Interfaces:

• MIPI-DSI: up to 2-lane, for high-resolution display output
• MIPI-CSI: up to 4-lane, for camera input
• USB 2.0 OTG HS: 480 Mbps
• SDIO: for SD card or Wi-Fi companion chip
• 2× SPI, 3× UART, 2× I2C, 3× I2S

Applications:

• High-resolution HMI panels and smart displays
• Machine vision and edge AI inference
• IP cameras and video streaming devices
• Industrial control panels
• Smart home hubs with display
• Medical imaging devices

Note: The ESP32-P4 does not include Wi-Fi or Bluetooth. For wireless connectivity, pair with an ESP32-C6 (Wi-Fi 6 + BT 5) or ESP32-H2 (Thread/Zigbee) module via SDIO/SPI. Espressif IDF v5.3+ is required for ESP32-P4 support.
