NUCLEO-F446RE STM32F446RE Nucleo-64 Development Board
Regular price
Rs.12,500.00
Sale price:
Rs.12,500.00
Regular price:
Sale:
-0%
Shipping calculated at checkout.
In stock, ready to ship
NUCLEO-F446RE — STM32F446RE Nucleo-64 Development Board
The NUCLEO-F446RE is ST Microelectronics' official Nucleo-64 development board built around the STM32F446RE — a 180MHz Cortex-M4 microcontroller with FPU, 512KB Flash, and 128KB RAM. In the compact Nucleo-64 form factor with Arduino Uno and ST Morpho headers, it is the most popular high-performance STM32 board for embedded development, motor control, and IoT prototyping in Pakistan.
Technical Specifications
| Parameter | Value |
|---|---|
| MCU | STM32F446RET6 (Cortex-M4, 180MHz) |
| Flash | 512KB |
| RAM | 128KB SRAM |
| FPU | Yes (single-precision) |
| GPIO Pins | 50 |
| Timers | 17 (including advanced motor control) |
| Communication | UART, SPI, I2C, CAN, USB OTG, SAI, SDIO |
| ADC | 3 × 12-bit, up to 16 channels |
| Debugger | On-board ST-LINK/V2-1 |
| Connectors | Arduino Uno + ST Morpho |
| Power | USB, VIN (7–12V), or 3.3V |
Key Features
- STM32F446RE: 180MHz Cortex-M4 with FPU — top performance in Nucleo-64 form factor
- 512KB Flash + 128KB RAM for complex applications
- On-board ST-LINK/V2-1 — program and debug without extra hardware
- Arduino Uno and ST Morpho headers for maximum shield compatibility
- USB Virtual COM port for easy serial debugging
- Supports STM32CubeIDE, Keil MDK, IAR EWARM, and Arduino IDE
Applications
- Embedded firmware development and prototyping
- Motor control and industrial automation
- DSP, audio, and signal processing
- IoT and wireless connectivity projects
- University embedded systems courses
Buy NUCLEO-F446RE STM32 Development Board at the best price from Embeded Studio.
