FDH055N15A MOSFET
FDH055N15A MOSFET Specifications Type Designator: FDH055N15A Type of Transistor: MOSFET Type of Control Channel: N -Channel Maximum Power Dissipation (Pd): 429 W Maximum Drain-Source Voltage |Vds|: 150 V Maximum Gate-Source Voltage |Vgs|: 20 V Maximum Gate-Threshold Voltage |Vgs(th)|: 4 V Maximum Drain Current |Id|: 118 A Maximum Junction Temperature (Tj):...
Regular price
Rs.225.00
Regular price
Rs.225.00
FDH055N15A MOSFET Specifications
- Type Designator: FDH055N15A
- Type of Transistor: MOSFET
- Type of Control Channel: N -Channel
- Maximum Power Dissipation (Pd): 429 W
- Maximum Drain-Source Voltage |Vds|: 150 V
- Maximum Gate-Source Voltage |Vgs|: 20 V
- Maximum Gate-Threshold Voltage |Vgs(th)|: 4 V
- Maximum Drain Current |Id|: 118 A
- Maximum Junction Temperature (Tj): 175 °C
- Total Gate Charge (Qg): 92 nC
- Maximum Drain-Source On-State Resistance (Rds): 0.0059 Ohm
055n15a mosfet in pakistan
