20MHz Crystal Oscillator


  1. Frequency Output: 20MHz – The crystal oscillator generates a stable clock signal at a frequency of 20 megahertz.
  2. Crystal Resonator Type: Quartz crystal resonator, known for its high stability and low phase noise characteristics, ensuring accurate frequency generation.
  3. Frequency Tolerance: Precise frequency control with low tolerance levels, typically within a few parts per million (ppm), to meet stringent timing requirements.
  4. Operating Temperature Range: Suitable for a wide temperature range, ensuring stable performance across various environmental conditions.
  5. Supply Voltage: Compatible with standard supply voltages commonly used in electronic systems, typically ranging from 3.3V to 5V.
  6. Output Waveform: Provides a clean and square wave output with minimal harmonics, making it suitable for digital applications.
  7. Output Load: Designed to drive standard loads commonly found in digital circuits, ensuring signal integrity and reliability.
  8. Start-up Time: Rapid start-up time, allowing for quick stabilization of the oscillator upon power-up.
  9. Aging Characteristics: Low aging rate, indicating minimal frequency drift over extended periods of operation.
  10. Package Type: Available in various package types, including through-hole and surface mount, to accommodate different PCB layouts and assembly processes.
  11. Phase Noise: Low phase noise characteristics, ensuring minimal signal jitter for precise timing applications.
  12. RoHS Compliance: Compliant with RoHS (Restriction of Hazardous Substances) directives for environmental safety.
  13. Application: Suitable for microcontrollers, microprocessors, communication systems, and other electronic devices where accurate timing is essential.
  14. Compatibility: Standard 20MHz frequency, ensuring compatibility with a wide range of electronic components and systems.



The 20MHz Crystal Oscillator is highly accurate, reliable, and ideal for precise clock signals in electronic circuits and systems.. Additionally, this oscillator incorporates a crystal resonator to ensure stable and consistent frequency output, making it ideal for applications where timing accuracy is crucial. Moreover, whether used in microcontrollers, microprocessors, or communication systems, the 20MHz Crystal Oscillator provides a dependable timekeeping solution for electronic designs.

The 20MHz Crystal Oscillator, a fundamental electronic component, offers stable, accurate clock signals, making it ideal for precise timing applications.
